P-TRAIN CNC
Status Quo neu definiert
Das satte HIGH PIVOT Fahrwerk vermittelt massive Traktion und Sicherheit auf rauen, schnellen Trails, verzichtet durch ein ausgewogenes Gesamtpaket aber nicht auf Trailbike Attitüden.
>> 29 Zoll, HIGH PIVOT (HPP) suspension
>> 135 oder 145mm Federweg für Trail- und Enduro riding
>> vollständig aus 7075er Aluminium CNC-gefräst
>> Klebeverbindung zweier dünnwandiger Schalenelemente
>> ADJUSTABLE RIDE° – Geometrie Anpassung nach deinen Vorlieben
DETAILS
| [mm] | |
|---|---|
| Intend Use | Trail, AM, Enduro |
| Material | CNC-machined from solid aluminum 7075-T6 |
| Geometry Setup options ADJUSTABLE RIDE° |
BB Height / Travel / Mullet / Chainstay Lenght / Head Angle |
| Max. Wheel Size | ≈ 29“ x 2,5“ (80 mm total) |
| Travel Rear ADJUSTABLE RIDE° |
145 (standard) / 135 |
| Travel Front | 140 – 160 |
| Rear Axle | 12 x 148 |
| Headset | IS41/28.6 – IS52/40 |
| Seat Tube inner Ø | 34,9 |
| Max. Insert Seatpost | S: 202 / M: 232 / L: 252 |
| Max. Chain Wheel Size | 34 |
| Shock Length | 210 x 55 Metric |
| Shock Hardware | 25 x 8 |
| Brake Mount | PM 180 |
| BB Type | 73mm BSA, ISCG 05 mount |
| Bottle Mount | 1 x Downtube topside 1 x Downtube bottomside |
| Weight | 4.000 g (S2, w/o shock) |
| Colors | Raw or anodized in champagne, black, blue, green, red |
| Shock Options | EXT STORIA LOK V3 CUSTOM TUNE FOX DHX2 F-S Cr 2pos-Adj FOX FLOAT X2 F-S K 2pos-Adj ÖHLINS TTX2Air ÖHLINS TTX22M others on request |
GEOMETRY
| S1 [mm] | S2 [mm] | S3 [mm] | |
|---|---|---|---|
| Reach | 455 | 475 | 505 |
| Top Tube Lenght | 602 | 622 | 652 |
| Stack | 618 | 627 | 636 |
| BB Height ADJUSTABE RIDE° |
LOW: 338 HIGH: 343* |
||
| BB Drop ADJUSTABE RIDE° |
LOW: -34 HIGH: -29* |
||
| Wheelbase ADJUSTABE RIDE° |
SHORT: 1200 LONG: 1207 |
SHORT: 1220 LONG: 1227 |
SHORT: 1250 LONG: 1257 |
| Chainstay Lenght ADJUSTABE RIDE° |
neutral / SAG / 50% / 100% SHORT: 423 / 434 / 438 / 441 LONG: 430 / 440 / 445 / 448 |
||
| Seat Angle effective | 77 deg | ||
| Seat Tube Length | 415 | 445 | 465 |
| Head Angle ADJUSTABE RIDE° |
BASE: 65° (±0° Headset Cup) SLACK: 64° (-1° Headset Cup) STEEP: 66 (+1° Headset Cup) |
||
| Head Tube Length | 105 | 110 | 120 |
| Reference Fork Length | 561 ( 150mm Travel )** | ||
| Reference Fork Offset | 46 | ||
| Reference Wheel Diameter | 744 | ||
| * BB Setting HIGH: Reach + 7 mm // BB Hight + 5 mm // Seat Angle +1 deg // Head Angle +1deg BB Setting HIGH recommended for 160mm Travel Front and 145 mm Travel Rear |
|||
| ** 140 / 160 mm Travel Front: Reach +7 / -7mm // BB Height -3 / + 3 mm // Wheelbase -4 / + 4 mm // Seat Angle +1/ -1 deg // Head Angle +1 / -1 deg |
|||
| Full geometry compensation for mullet. | |||
