P-TRAIN CNC

Redefining the status quo

The deep-feeling HIGH PIVOT suspension gives massive traction and confidence on fast, rough trails while not missing trailbike attitudes through a well-balanced package.

> 29 Zoll, HIGH PIVOT (HPP) suspension
>> 135 or 145 mm travel for Trail- and Enduro riding
>> CNC-machined from soild blocks of 7075 T6 aluminum
>> Adhesive bonding of two thin-walled shell elements
>> ADJUSTABLE RIDE° ready

GET YOURS

DETAILS

[mm]
Intend Use Trail, AM, Enduro
Material CNC-machined from solid aluminum
7075-T6
Geometry Setup options
ADJUSTABLE RIDE°
BB Height / Travel / Mullet /
Chainstay Lenght / Head Angle
Max. Wheel Size ≈ 29“ x 2,5“ (80 mm total)
Travel Rear
ADJUSTABLE RIDE°
145 (standard) / 135
Travel Front 140 – 160
Rear Axle 12 x 148
Headset IS41/28.6 – IS52/40
Seat Tube inner Ø 34,9
Max. Insert Seatpost S: 202 / M: 232 / L: 252
Max. Chain Wheel Size 34
Shock Length 210 x 55 Metric
Shock Hardware 25 x 8
Brake Mount PM 180
BB Type 73mm BSA, ISCG 05 mount
Bottle Mount 1 x Downtube topside
1 x Downtube bottomside
Weight 4.000 g (S2, w/o shock)
Colors Raw or anodized in champagne, black, blue, green, red
Shock Options EXT STORIA LOK V3 CUSTOM TUNE
FOX DHX2 F-S Cr 2pos-Adj
FOX FLOAT X2 F-S K 2pos-Adj
ÖHLINS TTX2Air
ÖHLINS TTX22M
others on request

GEOMETRY

S1 [mm] S2 [mm] S3 [mm]
Reach 455 475 505
Top Tube Lenght 602 622 652
Stack 618 627 636
BB Height
ADJUSTABE RIDE°
LOW: 338
HIGH: 343*
BB Drop
ADJUSTABE RIDE°
LOW: -34
HIGH: -29*
Wheelbase
ADJUSTABE RIDE°
SHORT: 1200
LONG: 1207
SHORT: 1220
LONG: 1227
SHORT: 1250
LONG: 1257
Chainstay Lenght
ADJUSTABE RIDE°
neutral / SAG / 50% / 100%
SHORT: 423 / 434 / 438 / 441
LONG: 430 / 440 / 445 / 448
Seat Angle effective 77 deg
Seat Tube Length 415 445 465
Head Angle
ADJUSTABE RIDE°
BASE: 65° (±0° Headset Cup)
SLACK: 64° (-1° Headset Cup)
STEEP: 66 (+1° Headset Cup)
Head Tube Length 105 110 120
Reference Fork Length 561 ( 150mm Travel )**
Reference Fork Offset 46
Reference Wheel Diameter 744
* BB Setting HIGH: Reach + 7 mm // BB Hight + 5 mm //
Seat Angle +1 deg // Head Angle +1deg
BB Setting HIGH recommended for 160mm Travel Front and 145 mm Travel Rear
** 140 / 160 mm Travel Front: Reach +7 / -7mm //
BB Height -3 / + 3 mm // Wheelbase -4 / + 4 mm // Seat Angle +1/ -1 deg //
Head Angle +1 / -1 deg
Full geometry compensation for mullet.
